Schüco
Schüco AWS 65 PASK
€0
High insulation thermal break tilt & slide system window system, with total face width of 117 mm.
Excellent practicality combining sliding opening and hung position; the list of its unique features is complemented by its excellent thermal insulation, sealing, soundproofing and burglar-resistance performance.
TECHNICAL CHARACTERISTICS
Dimensions:
- Frame profile depth: 65 mm
- Frame face width: 69 mm
- Maximum glass thickness: 4-45mm casement 11-55mm sheet mm
- Sheet profile depth: 75 mm
- Sheet face width: 78 mm
- Mechanism: 150kg SCHÜCO opening-hanging/sliding mechanism
- EPDM sealing gaskets
- Profiles have straight form
- Compatible with Schüco ADS 65 doors series
- Charge groups in accordance with DIN EN 12207/12208/12210Schüco TipTronic installation option and sheet weight 160kg
SPECIFICATIONS
- Thermal Insulation: Uf 2.2 W/m2K in accordance with DIN EN ISO 10077-2
- Soundproofing up to Rw=47dB in accordance with DIN EN ISO 140-3
- Burglar resistance up to RC2 in accordance with DIN V ENV 1627
- Air permeability in accordance with DIN EN 12207 Class: 4
- Water permeability in accordance with DIN EN 12208 Class: 9A
- Wind pressure resistance in accordance with DIN EN 12210: Class: C5 / B5
- Mechanical strength in accordance with DIN EN 13115 Class: 4
- Functionality over time in accordance with DIN EN 12400 Class: 3
TABLE CHARACTERISTICS
- Thermal Insulation: 4/5
- Waterproofing Index: 4/5
- Burglary Protection: 4/5
- Soundproofing: 4/5
- Streng Index: 4/5
