Schüco ASS 70 HI

Thermal break heavy duty lift & slide system, with total face width of 137mm.

A flexible solution offering many configuration options, such as double or tripe guide rail and inox rolling. The list of its unique features is complemented by its excellent thermal insulation, sealing, soundproofing and burglar-resistance performance.

TECHNICAL CHARACTERISTICS

Dimensions:

• Frame profile depth: 160mm
• Frame face width: Bottom 50mm
• Maximum glass thickness: 12-52mm
• Sheet profile depth: 70mm
• Sheet face width: 98mm

• Double and triple glass pane option
• Mechanism: 300kg lifting mechanism (up to 400kg option)
• EPDM sealing gaskets
• Profiles have straight form
• Thin-section frame to perimeter frame
• Many configuration options, choice between double or tripe guide rail and inox rolling
• Charge groups in accordance with DIN EN 12207/12208/12210

SPECIFICATIONS

• Thermal Insulation: Uf  2,8W/ m2K for the lifting system
• Soundproofing up to Rw=44dB in accordance with DIN EN ISO 140-3
• Burglar resistance up to RC2 in accordance with DIN V ENV 1627
• Air permeability in accordance with DIN EN 12207 Class: 4
• Water permeability in accordance with DIN EN 12208 Class: Ε1050
• Wind pressure resistance in accordance with DIN EN 12210: Class: C5 / B5
• Mechanical strength in accordance with DIN EN 13115 Class: 2
• Functionality over time in accordance with DIN EN 12400 Class: 4

TABLE CHARACTERISTICS

• Thermal Insulation: 4/5
• Waterproofing Index: 4/5
• Burglary Protection: 4/5
• Soundproofing: 4/5
• Streng Index: 4/5
