ELVIAL S46.SI2 (6700 i2)


Thermal break lift & slide system, with total face width of 122 mm.
The casement can be applied as a simple sliding system or as a lifting/sliding system for enhanced sealing. The system’s excellent air permeability, water permeability and wind pressure resistance performance is combined with the certified burglar-resistance features, for a complete protection of your place..



  • Frame profile depth: 113.1 mm
  • Frame face width: 47 mm
  • Maximum glass thickness: 24 mm
  • Sheet profile depth: 46 mm
  • Sheet face width: 85.5 mm

  • High thermal insulation performance thanks to the 18-24mm glass reinforced polyamide used
  • Mechanism: GU lifting mechanism (150kg) or simple sliding
  • EPDM sealing gaskets on the lifting system and brush sealing on the sliding system
  • Profiles have straight form
  • Smooth railing thanks to the inox guide rail it features
  • Charge groups in accordance with DIN EN 12207/12208/12210


  • Thermal Insulation: Uf 3,7 W/ m2K for the lifting system
  • Soundproofing up to Rw=36 in accordance with DIN EN ISO 140-3
  • Burglar resistance up to RC2 in accordance with DIN V ENV 1627
  • Air permeability in accordance with DIN EN 12207 Class: 4
  • Water permeability in accordance with DIN EN 12208 Class: 7Α
  • Wind pressure resistance in accordance with DIN EN 12210 Class: C1 / B2
  • Mechanical strength in accordance with DIN EN 13115 Class: 2
